Features

·        Conformance to IEC61010-1 CAT II 1000V/CAT III 600V

·        22000 Counts and 44 Bargraph Display

·        True RMS for AC voltage and current

·        RS232 Interface

·        Data Hold, MAX/MIN, Relative Measurement

·        AC Voltage / Current with 1kHz ‘LOW PASSED’Filter

·        AC Voltage /Current Peak Value Measurement

·        Logic frequency/ Linear frequency /Duty cycle measurement

·        Diode, Continuity Test

·        Temperature Measurement

·        Resistance Measurement

·        Capacitance Measurement

·        Clamp Measurement

·        Full Overload Protection

·        Power: 220V/110V AC or DC 9V
